Rectangular Duct Type Electric Heater

EKS electric duct heaters are designed for heating clean air in ventilation systems. The device casing is made of high-temperature resistant aluzinc coated steel. The heater elements are made of AISI 304 stainless steel. The heaters are equipped with 2 protective thermostats and screw terminals for easy connection. The casing has a rubber seal for air duct connection.

All EKS electric duct heaters have two-stage overheating protection:

1) The first stage is activated when the temperature reaches 50 °C (resets automatically - automatic reset function).

2) The second stage is activated when the temperature reaches 100 °C (resets manually with a button on the casing - manual reset function).

Heaters can be mounted vertically or horizontally. The maximum outlet air temperature is 50 °C. EKS does not have an internal temperature controller. In this case, external heating controllers EKR are used.
